🔐 Kubernetes ConfigMaps & Secrets Explained
In this tutorial, we explore how ConfigMaps and Secrets are used in Kubernetes to separate configuration from application code. This is a core concept for building secure, flexible, and production-ready workloads.
Overview 📘
- Creating and using ConfigMaps for configuration data
- Creating and using Secrets for sensitive information
- Mounting ConfigMaps as files
- Injecting Secrets as environment variables
1. ConfigMap Example 🧩
This ConfigMap stores HTML content that will be served directly by an nginx container. Instead of baking content into the image, we externalise it using Kubernetes.
apiVersion: v1
kind: ConfigMap
metadata:
name: nginx-config # Name used to reference this ConfigMap
data:
index.html: | # Key becomes a filename when mounted
<!DOCTYPE html>
<html>
<body>
<h1>Hello from ConfigMap!</h1>
<p>This content is loaded from a ConfigMap</p>
</body>
</html>
What’s happening here:
The data section contains key-value pairs.
When mounted as a volume, each key becomes a file.
In this case, index.html will be created inside the container and served by nginx.
2. Secret Example 🔑
Secrets are used to store sensitive data such as passwords, tokens, and API keys. Here, we store a simple message and expose it as an environment variable.
apiVersion: v1 kind: Secret metadata: name: nginx-secret type: Opaque # Generic key/value Secret stringData: # Allows plain text (auto base64-encoded) message: "This message comes from a Secret!"
Why stringData?
Kubernetes automatically base64-encodes values stored in stringData.
This avoids manual encoding and is easier to read during development.
3. Deployment Using ConfigMap & Secret ⚙️
This Deployment demonstrates two patterns: mounting a ConfigMap as files and injecting a Secret as an environment variable.
apiVersion: apps/v1
kind: Deployment
metadata:
name: nginx-configured
spec:
replicas: 1
selector:
matchLabels:
app: nginx-configured
template:
metadata:
labels:
app: nginx-configured
spec:
containers:
- name: nginx
image: nginx:1.14
ports:
- containerPort: 80
volumeMounts:
- name: config-volume # Volume reference
mountPath: /usr/share/nginx/html # Where files appear in container
env:
- name: SECRET_MESSAGE # Environment variable name
valueFrom:
secretKeyRef:
name: nginx-secret
key: message
volumes:
- name: config-volume
configMap:
name: nginx-config # ConfigMap source
How this works:
The ConfigMap is mounted as a volume, creating files inside the container.
nginx serves content from /usr/share/nginx/html,
so the mounted index.html is served automatically.
The Secret is injected as an environment variable and decoded automatically.
4. Service Configuration 🌐
To access the nginx pod from outside the cluster, we expose it using a NodePort Service.
apiVersion: v1
kind: Service
metadata:
name: nginx-configured-service
spec:
type: NodePort
selector:
app: nginx-configured
ports:
- port: 80
targetPort: 80
nodePort: 30091
This Service routes traffic from NodeIP:30091
to port 80 on the nginx container.
5. Command Reference 🧪
# Create ConfigMap and Secret
kubectl apply -f nginx-configmap.yaml
kubectl apply -f nginx-secret.yaml
# Deploy application
kubectl apply -f 04-config-deployment.yaml
# Create Service
kubectl apply -f 03-config-service.yaml
# Verify mounted ConfigMap file
kubectl exec -it \
$(kubectl get pod -l app=nginx-configured -o jsonpath='{.items[0].metadata.name}') \
-- cat /usr/share/nginx/html/index.html
# Verify Secret environment variable
kubectl exec -it \
$(kubectl get pod -l app=nginx-configured -o jsonpath='{.items[0].metadata.name}') \
-- env | grep SECRET_MESSAGE
6. Cleanup 🧹
kubectl delete deployment nginx-configured kubectl delete service nginx-configured-service kubectl delete configmap nginx-config kubectl delete secret nginx-secret
Wrapping Up 🧠✨
ConfigMaps and Secrets are one of those Kubernetes features that quietly change everything. They let you keep configuration flexible, sensitive data safe, and containers clean and reusable 🧼📦.
You’ve now seen how to:
- Separate configuration from application code ⚙️
- Inject config as files and environment variables 📄🌱
- Handle sensitive data the Kubernetes way 🔐
- Verify everything from inside a running pod 🔍
These patterns show up everywhere in real-world clusters — once they click, Kubernetes starts to feel a lot less magical and a lot more predictable 🧩.
👉 Next up: Resource Management & Health Checks 🚦
Take a breather, explore the pod, break things if you want — that’s how it really sticks 😄🔥
